  • Product description: SCMT120408/432-DTM, DH1055 SCMT432,CNC Square Lathe Inserts ,turning inserts,CNC Blade for steel maching Square Lathe Inserts ,turning inserts ,steel maching,carbide inserts, CNC blade,CNC cutting to
  •   Send Email

ISO Type: SCMT120408-DTM,SCMT432-DTM


Dimension (inch): L=0.500, I.C.=0.500, S=0.187, d=0.219, r=0.031


Workpiece Material (ISO): Steels (P10-P30)

Application: This insert is suitable for general-purpose medium machining of steels.


Chip Breaker: DTM


Chipbreaker for semi-finishing with wide application.M-class tolerance; suitable for boring and o.d. semi-finishing materials, like steel and cast iron etc.


Grade: DH1055

Grade Description: Thick TiCN + thick Al2O3 coating on carbide, a grade of Black Diamond Series For Steel Machining (color: black)

Comprising of thick TiCN and thick Al2O3 coatings, the grade has high capability against plastic deformation and good hardness of cutting edge. It is preferred grade for machining of steel from finishing to roughing. Under the same cutting conditions, the cutting speed can be increased by more than 25%, while the tool life can be 30% longer under the same cutting speed.



Note: Product sold in packs of 10 units.


Click here  to SCMT more specifications.
